Pluto Air Cooler
| Particulars | Pluto Air Cooler |
|---|---|
| Airflow (M3/H) | 22000 CMH |
| Discharge | Top / Bottom |
| Cooling Area (Sq. Ft.) | 2500 Sq. Ft. |
| Air Pressure (P.A) | 240 |
| Motor (V/Hz) | 380-415V / 50Hz & 220V / 50Hz |
| Power (Kw) | 1.5 |
| Phase | Three / Single |
| Speed | Single |
| Fan Type | Axial (4 Blade) |
| RPM (Running Per Minutes) | 1400 |
| Pad Size (MM) | 685 × 765 × 100 |
| Water Tank (LTR.) | 35 |
| Water Drain | Manual / Auto |
| Noise (DB) | < 75 |
| Net Weight (Kg) | Top - 68, Bottom - 62 |
| Dust Filter | Yes |
| Air Outlet Size (MM) | 670 × 670 |
| Dimension L×W×H (MM) | 1111 × 1111 × 1011 |
Industrial Ductable Air Cooler
Top & Bottom Discharge
Coolsup to 2500 sq.ft. (with 75 feet line up Ducting) 1.5 Unit Consumption in 1 Hour 22000 CMΗ
Advantages of Pluto Air Cooler
Benefits
Energy-Efficient Operation
- Consumes up to 80% less energy than traditional HVAC systems.
- Lower operational cost, especially suitable for continuous use.
Environmentally Friendly
- Uses natural evaporation process without harmful refrigerants.
- Lowers carbon footprint and promotes green cooling.
Easy Installation & Maintenance
- No ducting or complex piping required.
- Minimal maintenance with accessible components (fan, motor, pump, pads).
Fresh & Filtered Air Supply
- Pulls in fresh air, filters it through wet cooling pads, and removes dust and pollutants.
- Reduces indoor air pollution and improves air quality.
Effective Cooling for Large Areas
- Designed for high air delivery (measured in CMH/CFM)
- Uniform airflow covers wide spaces more effectively than traditional coolers
Operates in Semi-Open or Open Areas
- Ideal for environments where traditional air conditioning is ineffective or uneconomical.
- Suitable for partially ventilated areas with constant heat load.
Dual Voltage & Phase Options Available
- Available in single-phase and three-phase models with dual voltage (220V/380-415V).
- Flexible installation across different industrial setups.
